Product Description
Product Description
2CMQ-4 potato combine harvester is mainly used for harvesting potato,garlic,sweet potatoes,peanuts and other crops,underground stems, which can finish digging, crashing soil, cleaning impurity, grading and bagging during one operation in high working efficiency.
Specification
Model
2CMQ-4
Motor power(kW/hp)
≥88.2/120
Rows
4
Working speed(km/h)
3~5
Working efficiency (hm2/h)
1.0~1.56
Row space(mm)
800/850/900
Planter distance(mm)
120~380
Fertilizer quantity(kg/hm2)
140~1100
Seed box volume(kg)
3000
1, Earth leakage quickly, not fruit falling, not peeled, tidy placement, the high rate of potato. 2, Residual film recovering clean, efficient fast finish the potato digging 3, Both sides with the harvesting cutter, with cranberry harvest not crowded grass, soil jam, work flow 4, Conveyor chain with unique design, durable 5, Using frame structure, lightweight, durable, more convenient installation. 6.It also features at high efficiency, low failure rate, smooth running without vibration, simple structure and long service life,etc., with no grass blocking or clod leakage during working.
Feature
1. Joint operations such as ditching, sowing, fertilizing, spraying, earthing, etc. can be completed once.
2. The design of large-capacity fertilizer boxes and seed boxes reduces the number of additions and additions of fertilizers and improves the operating efficiency.
3. Adopting auger push fertilizer system, a wide range of fertilizers can be adjusted, and fertilization is precise.
4. Both sides of the ridge body are fertilized, the depth of fertilization is adjustable, and the fertilizer utilization rate is high.
5. Seeding belt adopts electronic vibrating to reduce seeding and improve seeding accuracy.
6. The bottom of the seed box mechanically shakes and prevents the seeding mechanism, eliminating the need for manual pushing of the seed link, ensuring that the seedling spoons are continuously fed, and minimizing the leaking seeding rate.
7. The sowing monomer is equipped with a depth-limited wheel to ensure the consistency of sowing depth and improve the sowing quality.
8. The original parts are imported, the machine performance is stable, reliable and long service life.
9. Traction sowing, low power demand, to meet the needs of customers.
